144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use

144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use
Özellikleri Fotoğraf Galerisi Ürün Açıklaması Fiyat talebi
Özellikleri
Teknik Özellikler
gölgelik: Özelleştirilmiş
Garanti: 12 Ay/1000 Saat
tip: Sessiz (süper Sessiz) veya Açık, Sessiz, vb., Sıralı/6 Silindirli/4 Zamanlı/4 Valfli/19L, Ses Geçirm
Kontrol Paneli: LCD Dijital Ekran, Derin Deniz, ComAp, Derin Deniz / ComAp / Harsen / Smartgen 6110, Smartgen
Çıkış türü: AC Tek/Üç Faz
Denetleyici: Derin deniz/Smartgen/vb
Başvuru: Indursty bankası vb.
Nominal gerilim: 400/230V, 110-480V, 220V / 380V, 110V / 240V, 380V
Alternatör: Marathon, Stamford, SLG/Stamford/Marathon/Meccatle/Leroy-somer, Stamford veya Newtec, Engga
Ürün adı: Ev kullanımı, endüstriyel kullanım, hastane kullanımı ve inşaat sahaları için özelleştirilebilir PER
Renk: Müşterilerin Gereksinimi
Sıklık: 50/60HZ
Nominal güç: 180KVA
Motor: Orijinal Perkins
Soğutma Yöntemi: Su Soğutma Sistemi
Vurgulamak:

180KVA silent diesel generator

,

144kW Perkins generator with ATS

,

home use diesel generator set
Temel bilgiler
Menşe yeri: Çin
Marka adı: PERKINS
Sertifika: CE
Model numarası: 1106A - 70TAG3
Ödeme & teslimat koşulları
Ambalaj bilgileri: Kontrplak
Teslim süresi: 30 gün
Yetenek temini: Ayda 500 adet
Ürün Açıklaması
144kW 180KVA Customizable Silent Diesel Generator Sets
Hot sale customizable silent diesel generator sets with automatic transfer switch option for home use
Product Introduction
Our 144kW 180KVA BOBIG PERKINS diesel generator (Model: 1106A-70TAG3) is designed to provide reliable power for a wide range of applications. Backed by the renowned PERKINS brand, it offers high-quality performance and long-term durability.
Key Features
Power Performance
Rated Power: With a rated power of 144kW (180KVA), it can meet the power needs of various industrial, commercial, and residential applications. The prime power output is stable and efficient, ensuring continuous operation even under heavy loads.
Frequency: The generator operates at a standard frequency of 50Hz, which is suitable for most electrical equipment in the market.
Engine Excellence
Engine Model: Powered by the 1106A-70TAG3 PERKINS engine, it combines advanced technology and high-quality manufacturing. The engine is known for its high torque, fuel efficiency, and low emissions.
Engine Speed: Running at 1500 RPM, it provides a smooth and consistent power supply while minimizing wear and tear on the engine components.
Applicable Standards
Our generator complies with multiple international and national standards, including ISO 8528-5:2018, GB/T2820.5-2009, and CE. These certifications guarantee the quality, safety, and reliability of the product.
Environmental Adaptability
Ambient Temperature: It can operate effectively in an ambient temperature range of +5°C to +40°C.
Altitude: The generator is suitable for use at altitudes of up to 1000m. If your environmental conditions are different, our sales team is ready to assist you with customized solutions.
Technical Specifications
General Information
Parameter Prime Power Standby Power
Rated Power (kVA) 180 198
Power Rating (kW) 144 158
Frequency (Hz) 50
Engine Model 1106A-70TAG3
Engine Speed (RPM) 1500
Phase 3
PF 0.8
Control System Digital
Rated Voltage (V) 400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time ≥ 8h @ 75% load
PRP: Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP: The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Dimension and Weight
Model BP198 (Open type) BP198S (Silent type)
Length (mm) 2400 3250
Width (mm) 820 1040
Height (mm) 1550 1500
Tank Capacity (L) 331 331
Engine Specifications
Engine Model & Manufacturer 1106A-70TAG3 (PERKINS)
Emission Certification ----
Number of Cylinders 6
Cylinder Arrangement Vertical inline
Cycle Four stroke
Aspiration Turbocharged and air charge cooled
Bore x Stroke 105 x 135 mm
Cubic Capacity 7.01 L
Compression Ratio 16.0:1
Prime Power/Speed 157.7 kW/1500 rpm
Standby Power/Speed 175.2 kW/1500 rpm
Governor Type Mechanical
Cooling System Force Water Cooling Cycle
Transient Frequency Deviation -0.833333333
Total Lubrication System Capacity 12.5 L
Coolant Capacity (engine only) 18.0 L
Fuel Consumption (100% load) 209 g/kWh @1500 rpm
Starter Motor DC 24V
Charge Alternator DC 24V
Alternator Specifications
Alternator Brand BOBIG
Alternator Manufacturer FUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator Model BW-274G
Alternator Rated Power 144kw/180kva
Rated Voltage (V) 230v/400v
Rated Frequency 50hz
Connecting Type 3 Phase and 4 W
Number of Bearing 1
Protection Grade IP23
Altitude ≤1000m
Exciter Type Brushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation Class H class
Telephone Influence Factor (TIF) ≤50
THF ≤2%
Voltage Regulation, Steady State ≤±1%
Transient State Voltage ≤-15%~+20%
Customization & Features
We support customization and OEM services. (There will be design drawings.)
All the units are equipped with original power supplies and come with the standard DSE 6120 controller. (Engine is optional, generator is optional, controller is optional)
144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use 0
Packaging & Shipping
Plywood case, 10~15 working days after receiving customer's order.
Certifications
144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use 1 144kW 180KVA Hot Sale Customizable Silent Diesel Generator Sets with Automatic Transfer Switch Option for Home Use 2
Applications
This diesel generator is ideal for a variety of applications, such as:
  • Industrial Use: It can be used as a backup power source for factories, ensuring continuous production during power outages.
  • Commercial Buildings: Office buildings, shopping malls, and hotels can rely on it to maintain essential services like lighting, elevators, and security systems.
  • Residential Areas: Provide reliable power to residential communities, especially in areas with unstable power grids.
Warranty and After-sales Service
We offer a comprehensive warranty for our diesel generators. Our professional after-sales service team is available 24/7 to provide technical support, maintenance, and repair services to ensure your peace of mind.
BOBIG products have guarantee for one year or 1000 hours whichever reach first from ex-factory date. During the guarantee period, we will provide the free easy-damageable spare parts, caused by our quality of production or raw material. After expiration, we provide cost spare parts maintenance.
Why Choose Us
  • Brand Reputation: Engine is a well-known and trusted brand in the diesel generator industry, with a long history of producing high-quality products.
  • Quality Assurance: Our products are manufactured in strict accordance with international standards, and each generator undergoes rigorous quality inspections before leaving the factory.
  • Customization Options: We understand that different customers have different needs. Our team can provide customized solutions based on your specific requirements.
Frequently Asked Questions
1. What is your MOQ, payment method, delivery time?
Answer: Our MOQ is only 1 set. Payment method usually is 30% T/T as deposit, 70% balance T/T before delivering. Or 100% L/C, trade assurance, PayPal, Western Union. Delivery period normally will be 10~15 working days after receiving customer's deposit.
2. Which port do you often use when export?
Answer: Fuzhou port, Fujian province or as customer request.
3. Is there any spare parts you can provide along with generators to make the maintenance convenient?
Answer: We can provide regular engine's air filter, water filter, fuel filter, oil filter to customers for self-maintenance.
4. Can you offer parts to us if we need?
Answer: Yes, we can offer parts to you at any time, not limited in warranty time. Usually the parts can be sent out during 3-5 days.
5. For voltage, frequency, tank capacity, phase and color, can you made accord with our requests?
Answer: Yes, they can be made accord with your need.
6. If I want to be your products distributor in our country, what is your distribution policy?
Answer: Welcomes everybody join us and distribute products worldwide. We can issue authority certificates and sign agreement with you accordingly.
